7Mm Analog Camera Module

This is a specialized lens for industrial endoscopes, and “AV” represents an analog video output method. Please understand! It should be emphasized that this is only an industrial analog output endoscope module, not a monitoring camera.

Main parameter description

• 1. This module is a CVBS (AV standard) video analog lens module, mainly used for display devices such as car displays, televisions, hard disk recorders, etc. If connected to a computer or computer monitor, customers need their own adapters for their devices. Please check on your own!
• 2. The working voltage of the module is 3.3-5V. If it is powered on at 12V, there needs to be a voltage reducing device on the wire soldered at the back end to reduce it to within 5V. There are ready-made voltage reducing wires on the market that can reduce it to 3.3-3.7V.
• 3. The default focal length of the lens is usually around 3-8cm (our company is not responsible for product damage caused by self adjusting the lens focus).
• 4. The module is not waterproof

Product parameters

• Module dimensions: 12.3mm x7mm
• Working temperature:- 30℃ to 85℃
• Signal to noise ratio: 45dB
• Dynamic range: 60dB
• Resolution: 640HX 480V
• Output method: CVBS PAL NTSC
• Pixel size: 3.6 μ m x 3.6 μ m
• Fixed mode noise:< 0.1%
• Main beam angle of lens: 15 °
• Sensitivity: 10V/Lux * S
• Shutter mode: electronic roll cloth
• Shutter speed: 1/50
• Scanning mode: interlaced scanning
• Minimum illumination: 0.1LUX
• Chip size: 1/6.25
• Module power consumption: 60uA
• Output frame rate: 50pfs/s
• Supply voltage: 3.3V-5V
• Chip packaging: CSP
• Dark current: 5mV/s @ 40 ℃
• Lens specification: 1/6.25
• Automatic zoom adjustment range of lens: 3.5cm-7cm
• LED color temperature: 5500K-6500K
• Lens Construction：3P+IR
• F/No：2.8
• EFL：3.34mm
• FOV：68°
• TV Distortion：<1%
• Chip contrast ratio: 38.5%
• Filter parameters: 650 ± 10nm
• Exposure gain white balance: automatic
